Inlet: -10AN Outlet: -10AN
AEM's Universal High Flow -10 AN Inline Filter is specifically engineered for maximizing flow without sacrificing filtration, and is designed for ease of installation. The end caps are machined with -10AN female fittings that allow the filter to flow up to 12.32 gpm @ 45 PSI and 2.63 gpm @ 6 PSI. Machined O-ring receiver grooves on the end caps ensure against leaks, and all sealing o-rings and gaskets are made of Viton for outstanding performance when using gasoline, alcohol or gasoline/alcohol blended fuels. The commonly available replacement filter cartridges filter particles as small as 7 microns. The filter's standard 2" OD allows for easy mounting virtually anywhere in the vehicle for easy access.
AEM's Universal High Flow -10 AN Inline Filter is specifically engineered for maximizing flow without sacrificing filtration, and is designed for ease of installation. The end caps are machined with -10AN female fittings that allow the filter to flow up to 12.32 gpm @ 45 PSI and 2.63 gpm @ 6 PSI. Machined O-ring receiver grooves on the end caps ensure against leaks, and all sealing o-rings and gaskets are made of Viton for outstanding performance when using gasoline, alcohol or gasoline/alcohol blended fuels. The commonly available replacement filter cartridges filter particles as small as 7 microns. The filter's standard 2" OD allows for easy mounting virtually anywhere in the vehicle for easy access.
- Flows up to 12.32 gpm @ 45 PSI and 2.63 gpm @ 6 PSI
- Filters particles as small as 7 microns
- Machined from 6061-T6 aluminum with a black hard anodized finish
- Viton o-rings and gaskets ensure outstanding performance when using gasoline, alcohol or gasoline/alcohol blended fuels
- End caps are machined with -10 AN female fittings with o-ring receiver groove
- End caps have pressure intensifiers for greater sealing of end gaskets
- 2" OD x 10" length for easy mounting
- Commonly available replacement filter cartridges
- Laser etched with AEM logo, flow and comes with filter replacement information
| Attributes | |
| Brand | AEM |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov, WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Air and Fuel Delivery |
| Color | Black Anodized, Black Anodized |
| Country of Origin (Primary) | US |
| Diameter | 2.00 inch, 2.00 inch |
| Element Material | Depth Media, Depth Media |
| Emission Code | 5, 5 |
| Filter Type | Post Filter, Post Filter |
| Fuel Type | Gasoline / Diesel / E85, Gasoline / Diesel / E85 |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| Hazardous Material Code | N |
| Inlet Size | 10 AN O-ring, 10 AN O-ring |
| Length | 10 inch, 10 inch |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum, Aluminum |
| Micron | 7 Micron, 7 Micron |
| NAFTA Preference Criterion Code | B |
| Outlet Size | 10 AN O-ring, 10 AN O-ring |
| part type | Fuel Filter |
| Product Type | Fuel Filter, Fuel Filter |
| SDR Required Flag | N |
| Sub Category | Filters, Filters |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | 1 Year, Manufacturer's 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00840879021528 |
